Automatic Sleeve Shrink Labeling Machine From China DATONG
DT Ref: OG-100140
cyclotron cut-off, double sided cutting edge with a long service life. Single positioning center guide pillar: a more stable for label
delivery. Independent feeding material shelf: the position of the material shelf is optional at will.
Order Information:
- Payment Options: Available on Request
- Delivery Time: Available on Request
- Shipping Zones: Worldwide
Description
Additional Information
OG-150 Model Auto sleeve shrink machine
1.Model： OG-150 Auto sleeve shrink machine / 1set
2..Main parameter：
Machine size：2100L*850W*2000H (mm)
Machine body material and weight ：SUS304 ，700Kgs apporximate(Main machine )
Applicable bottle diameter range: Ф28 mm-Ф125mm
Applicable bottle height：30 mm -250 mm
Label length：28 mm ~120mm， Label edge transparent should be more than 5mm
Label thickness：0.03 mm ~0.13 mm（PVC, PET, OPS, applicable）
Paper pipe inner diameter:5”~10”， can be adjusted freely.
Capacity：100b/m(Round bottle, after filling，bottle outside should be dryed，Label length whthin100mm )
Power specification:∮3,380/220VAC
Power consumption: 1.5KW
Conveyor： Standard 2M (This machine does not include a conveyor connector or motor.)
3.Producing efficiency: 100b/m，Label feeding round plate ，Micro computer control；Auto sensor；Change label quickly ，Cut precisely.
4. OG-150 Model The capacity is smaller than the other model but it takes the same PLC, Fixing Module, Stepping motor, and Touch screen as the higher-speed machines.
5. Applicable bottles: All kinds such as round bottles, square bottles, flat bottles, curve bottles, and so on.
SHRINK TUNNEL WITH THE AIR BLOWER
1. The new type of shrink tunnel is based on different kinds of bottles and different shapes of bottles like round bottles, square bottles, and flat bottles. This machine is easily operated and easily adjusted. The steam spurting uses using seamless tube.
2. Size: 1.8mX0.46mX1.8m
STEAM GENERATOR
1. Input power specification：380V
2. Power consumption：18KW
3. Steam pressure：0.25-0.4Mpa
4. Steam capacity：24Kg/h;
5. Size：600cm×550cm×1200cm（LxWxH）
6. Weight：196Kg
